Land Pride AB72

New / Land Pride / Snow Tools / AB Series Angle Brooms / AB72

Land Pride AB72 for sale at Pillar Equipment, Quad Cities Region, Illinois

Double tap to zoom

Land Pride AB72 for sale at Pillar Equipment, Quad Cities Region, Illinois



Features

FEATURES BENEFITS
32" Bristle Diameter Provides for long service life.
Choice of poly or wire or combination poly/wire bristles Allows owner/operators to meet operational needs. Wire or poly/wire combinations provide more wear life and more aggressive sweeping action.
Faceted hood design Provides for a higher level of overall structural integrity.
Easily removable brush drive Allows for quick and easy change out of brushes without motor removal or opening hydraulic lines.
Choice of manual or hydraulic angling Allows owner/operators to meet budgetary and operational needs. High or regular flow hydraulic options are offered to ensure that cylinder travel response is safe and appropriately matched to output flow of the tractor.
Brush angles 30 degrees to the left or right Provides for excellent material control and puts sweepings where the operator wants them.
Compatible with 12GPM to 25GPM hydraulic flow at 2,000 psi Allows attachment to a wide range of skid steers and compatible compact utility tractors equipped with loader arms and skid steer adapter plates.
Integral flow control valve Protects hydraulic system and motor from hydraulic inputs exceeding 25 GPM.
Integral float control design Spring loaded adjustable down pressure control and stops prevent premature brush wear while providing appropriate surface contact with the rotary brush.
100 to 230 rpm brush rotation Provides for good sweeping action and material control.
Integral storage stands Enables easy dismount and storage and keeps bristle ends from becoming deformed by supporting weight of the unit.
Options
Rubber Dust Deflector Flap Helps keep dust levels under control and down and under the hood cowling and out of the operators field of vision.
Dust Suppression system Hood mounted spray boom and nozzles dispense a fine spray mist in front of the broom to control and minimize airborne dust particles.
Metal Shroud Extension Extends the broom shroud further forward to help control dust. Spray nozzles can be mounted on the extension to help minimize airborne dust particles.
Marker Indicators Aids operator in knowing exact position of extreme left and right edges of the unit for safer and unencumbered operation.

Specifications

Model Number AB72
Hitch Skid steer quick attach, meets ISO 24410
Weight w/ high flow set-up, hydraulic angling jack and combination broom 854 lbs (387.4 kg)
Overall width 81 1/2" (2.07 m)
Overall height 33" (83.8 cm)
Wafer quantities,
poly or wire		 2 Straight Poly Wafers
34 Convoluted Wafers
Wafer quantities,
combination poly and wire		 2 Straight Poly Wafers
34 Convoluted Wafers
Sweeping width 72" (1.83 m)
Sweeping width @ 30o max angle 65" (1.65 m)
Maximum angle Manual Angling: 30 Degrees left or right Optional Hydraulic Angling: 30 Degrees left or right
Brush diameter 32" (81.3 m)
Brush rotor shaft Quick change broom core with no hydraulic breakage in changeover
Hex drive system Replaceable
Brush bristle type 100% Poly or 100% Metallic or 50% Poly and 50% Metallic
Hood Sheet Metal
Jack stands Standard
Float Control Spring Loaded with adjustable down pressure and stops
Hydraulic gpm range 12-30 gpm (45.4-113.6 pm)
Motor rated hydraulic flow
18 CID motor
23 CID motor
18 gpm (68.1 lpm) @ 220 rpm brush speed (“High Flow” option not available.)
25 gpm (94.6 lpm) @ 230 rpm brush speed (“High Flow” option available for units capable of producing flows above 25 gpm (94.6 lpm). This option protects the hydraulic motor by diverting excess flow back to the tank.)
Minimum hydraulic flow required 12 gpm (45.4 lpm) @ 2000 PSI (13.79 MPa)
Maximum hydraulic pressure rating 3500 PSI (24.13 MPa)
Brush speed range 100 - 230 Rpm
Hydraulic rotor drive motor Single motor drive standard
Hydraulic hoses Standard for drive motor hook-up Optional with angling cylinder
Hydraulic couplers Standard
