Land Pride SSG2524

Land Pride SSG2524 for sale at Pillar Equipment, Quad Cities Region, Illinois

Double tap to zoom

Land Pride SSG2524 for sale at Pillar Equipment, Quad Cities Region, Illinois



Features

Features Benefits
Universal quick attach mounting system For quick and easy attachment.
8" Digging depth A good depth below the ground. Removes base of most trees.
Adjustable skid shoes Adjustable to fit all sizes of skid steers
Pivoting discharge deflector Discharge deflector pivots up while cutting wheel is digging into the ground.
Welded on serrated step Good safe step for accessing skid steer operator’s seat.
High speed cutting wheel Cuts faster with less vibration.
Permanent hose holders Hoses aren’t zip-tied to the frame. Zip ties can break over time.
Replaceable carbide cutting teeth Cutting teeth are easy to replace. Carbide tips for extra long life.
Hydraulic hose lines Hydraulic hoses absorb shock. Steel hydraulic lines crack from vibration.
Case drain hydraulic line Protects against component damage.
Keyed, tapered spindle on end of hydraulic motor Able to draw cutting wheel tight against the tapered shaft providing an excellent fit-up and less likely to shear the key off.
Cutting wheel designed with wheel puller access holes Makes it easier to pull the cutting wheel off of the motor spindle.
Attached rain tight manual holding tube Keeps manual with stump grinder for quick easy access. Manual won’t get wet
Offset articulating arm Allow for optimum line-of-site from operator’s seat

Specifications

Mounting Plate Quick Attach
Main Frame in (mm) 6 x 6 x 1/4 (152 x 152 x 6) Tube
Overall Mounting Width in (m) 48 (1.22)
Overall Length in (m) 60 (1.52)
Overall Weight lbs (kg) 540 (244.9)
Drive And Control System Hydraulic motor with electric over hydraulic
Hydraulic Requirements gpm (Lpm) 17 to 32 (64.4 to 121.1)
Cutting Wheel Speed 470 to 875 rpm
Articulate Cylinder in (cm) 3 (7.6) x 6 (15.2) stroke with 1 1/4 (3.2) rod dia.
Tilt Cylinder in (cm) 3 (7.6) x 6 (15.2) stroke with 1 1/4 (3.2) rod dia.
Hydraulic Lines & Hoses in (mm) 3/4 (19) I.D. Hydraulic hoses with crimp on cordura sleeve
1/4 (6) I.D. Case drain hydraulic hose
Number of Cutting Teeth
Straight
Left-Hand
Right-Hand

8 - Replaceable carbide teeth
12 - Replaceable carbide teeth
12 - Replaceable carbide teeth
Cutting Arc 55 Degrees
Maximum Cutting Depth Below Ground in (cm) 8 (20.3)
Greasable Hinge Points Yes
Color Black
Outside Cutting Wheel Diameter in (cm) 23 3/4 (60.3)
Cutting Wheel Thickness in (mm) 1/2 (13)
Maximum Pressure Rating psi (mPa) 3500 (24.1)
