Land Pride HB74

New / Land Pride / Material Handling / HB Series Hopper Broom / HB74

Land Pride HB74 for sale at Pillar Equipment, Quad Cities Region, Illinois

Double tap to zoom

Land Pride HB74 for sale at Pillar Equipment, Quad Cities Region, Illinois



Features

Features Benefits
Available in 74" ( 1.88m) and
84" (2.13 m) working widths		 Provides for excellent productivity and ideal sizes for most skid steers and compact utility tractors.
Connect under pressure hydraulic couplers Coupler are easier to connect and disconnect under pressure.
Direct drive motor Improves efficiency.
Forward and rearward travel Broom can operate while traveling forward or backward. Gutter broom must be shut off when operating backward.
26" (66 cm) Bristle diameter Provides for long service life.
Choice of poly, wire, or combination poly/wire bristles Allows owner/operators to meet operational needs. Poly/wire combinations provide more wear life and more aggressive sweeping action.
Easily removable brush drive Allows for quick and easy change out of wafers.
If included, only case drain hydraulic line must be disconnected.
Adjustable broom hood Broom hood can be adjusted down as the bristles wear to extend the life of the broom.
Reversible & replaceable cutting edge Increases cutting edge life and can be replaced when worn out.
Compatible with 12- 25 gpm (45-95 Lpm) hydraulic flow Allows attachment to a wide range of skid steers.
Up to 230 rpm brush rotation Provides for good sweeping action and material control.
Rubber dust deflector flap Helps keep dust levels under control and down and under the broom hood and out of the operators field of vision.
Optional gutter broom Makes it easier to clean curbs and along side buildings. Adds 12" (30.5 cm) to the cleaning width.
Optional dust suppression kits Wets the dust before sweeping it to help keep airborne dust down to a minimum.

Specifications

Specifications & Capacities
Model Number HB74
Hitch Skid steer quick attach, meets ISO 24410
Weight of base unit without broom 1030 lbs (467 kg)
Broom weights
Poly broom
Wire broom
Combination broom
222 lbs (101 kg)
222 lbs (101 kg)
222 lbs (101 kg)
Optional weights
Gutter broom
Dust suppression
Dust suppression (Main & gutter broom)
101 lbs (46 kg)
194 lbs (88 kg)
197 lbs (89 kg)
Overall width 82" (2.08 m)
Overall height 46" (1.17 m)
Wafers
Poly broom
Wire broom
Combination broom
36 Poly wafers
36 Wire wafers
18 Poly & 18 wire wafers
Sweeping width 74" (1.88 m)
Sweeping width with gutter broom 86" (2.18 m)
Broom diameter 26" (66 cm)
Broom rotor shaft
Without gutter broom
With gutter broom
Quick change broom core with no hydraulic hose disconnect in changeover.
Quick change broom core with return to sump hydraulic hose disconnect only.
Square drive system Replaceable
Broom bristle type 100% Poly, 100% wire, or 50% poly and 50% wire
Hydraulic gpm range 12-25 gpm (45-95 Lpm)
Minimum hydraulic flow required 12 gpm (45 Lpm) @ 2000 psi (13.8 mPa)
Maximum hydraulic pressure rating 3500 psi (24.1 mPa)
Broom speed range 100 - 230 rpm
Hydraulic rotor drive motor Single motor drive standard
Hydraulic hoses Standard
Hydraulic couplers Standard flat faced couplers
Bucket shell thickness 3/16"
Bolt-on cutting edge Standard 5/8"x 8"
Broom hood thickness 12 ga sheet metal
Optional water tank capacity 25 gal (95 L)
