Land Pride CPF1236

Land Pride CPF1236 for sale at Pillar Equipment, Quad Cities Region, Illinois

Double tap to zoom

Land Pride CPF1236 for sale at Pillar Equipment, Quad Cities Region, Illinois



Features

Features Benefits
CII Hitch The Compact Pallet Fork can be easily attached to the compact loader
Tall rear guard Keep loads from slipping backwards.
Easy adjustable forks Forks slide easily on carrying bars from one position to another. Simply rotate
locking handles up and slide forks to their new positions. Rotate locking handles down
to secure forks in their new position.
Two fork lengths
1,200 lbs. with 36" forks
1,200 lbs. with 42" forks
Meets most needs for load handling on customer owned compact loader.

Specifications

Model CPF1236
Weight lbs. (kg) 224 lbs. (102 kg)
Lift capacity lbs. (kg) 1,200 (544 kg)
Lift capacity is based on load being 24" (61 cm) from vertical face of fork. Load must be palletized and supported by two forks.
Class  I
Frame width in. (cm)  35 1/2" (90.17 cm)
Frame height in. (cm)  31 3/4" (81 cm)
Tine thickness in. (cm)  1 1/4" (3 cm)
Tine width in. (cm)  3" (8 cm)
Tine length in. (cm)  36" (91 cm)
Fork positioning lock  Spring Loaded Toggle
