Land Pride SC4060

New / Land Pride / CE Attachments / SC40 Series Skid Steer Cutters / SC4060

Land Pride SC4060 for sale at Pillar Equipment, Quad Cities Region, Illinois

Double tap to zoom

Land Pride SC4060 for sale at Pillar Equipment, Quad Cities Region, Illinois



Features

Features Benefits
Standard motor @ 15-26 gpm

High flow motor @ 27-43 gpm		 Customer can choose one of two optional motors for the SC4060 or SC4072 cutter
(standard and high flow). This allows the cutter to fit a wide variety of Skid Steers.
Also the deck can be upgraded to a different motor when owner upgrades Skid Steer
Case drain Protects hydraulic motor
1/4" Side panels for
overall reinforcement		 Protects sides from debris being thrown against them from the blades.
Front and rear chain guards Single chain guards on the front and rear of deck. Reduces flying debris.
Replaceable skid shoes Protect side plate structure. Shoes are replaceable for convenience.
1/2" x 5" Heat-treated
free-swinging blades		 Heat-treated blades offer longer life.
Free-swinging blades protect from obstructions
4" Diameter cutting capacity Can aid in clearing brush.
SC4060 High blade tip speed Standard motor = 14,455 fpm at 26 gpm.
High flow motor = 15,440 fpm at 43 gpm.
SC4072 High blade tip speed Standard motor = 17,345 fpm at 26 gpm.
High flow motor = 18,527 fpm at 43 gpm.
Optional front roller wheels Aid in the forward motion of the cutter and help protect against running the cutter
frame into the ground. The rollers will also help in lengthening the life of the cutter’s
front end skid shoes
Motor pressure gauge Allows the operator to ensure that the motor is operating at proper psi.
Bi-directional blade rotation Customer can switch direction of blade rotation to utilize both sides of blades.
Height adjustment safety chain Provides additional operator protection from flying objects by allowing the Rotary
Cutter to only be lifted up to 18".

Specifications

Model Number SC4060
Cutter weight with skid shoes and
without front roller wheels		 1324 lbs.
Front roller wheels weight (Optional) 42 lbs (19.1)
Protective door weight (Optional) 10 lbs (4.5)
Hitch Welded on
Cutting width 61.5 (1.56)
Overall width 72 (1.83)
Overall length 78 (1.98)
Cutting height 1 1/2 to 18 (3.8 to 45.7) infinitely variable.
Cutting capacity 4 (10.2) Diameter
Spindle hub oil capacity 10 (296)
Spindle hub oil EP 80-90 wt. gearlube
Standard drive motor 15-26 (56.8-98.4) flow
High volume drive motor 27-43 (102.2-162.8) flow
Hydraulic pressure 1500 to 3500 (10.34 to 24.13)
Deck thickness 1/4 (6)
Side skirt construction 1/4 (6) Steel
Deck wear protection Four corner-mounted skid shoes and two mid skid shoes
Skid shoes construction 3/8 (10) plate
Dishpan Heavy-duty round 5/8" plate
Blade size 1/2" x 5" bi-directional
Blade rotation Clockwise or Counter clock wise
Blade Bolt 1 1/8"-12 x 3 7/16" with key.
16-26 gpm motor blade tip speed
27-43 gpm motor blade tip speed		 14455 (73.4) at 26 (98.4)
15440 (78.4) at 43 (162.8)
Front deck protection Single row chain guard
Rear deck protection Single row chain guard
Deck lift height protection Height adjustment safety chain
Front rollers (Optional) Welded round steel wheels
